Onten OTN-9573S USB-C to Hdmi/Vga/Audio Hub 4K
The Onten OTN-9573S (Model: OTN-9573 / OTN-U9573S) is a multi-port Type-C audio-video adapter and docking station engineered to expand the display and connectivity capabilities of modern laptops, MacBooks, tablets, and smartphones. Built with a dual video output controller, it converts a single USB Type-C or Thunderbolt 3/4 port into five distinct connectivity options: a 4K Ultra HD HDMI port, a 1080p Full HD VGA port, a 3.5mm AUX audio jack, a SuperSpeed USB 3.0 Type-A port (5 Gbps), and a 100W USB-C Power Delivery (PD 3.0) pass-through charging port. Enclosed in a premium anodized aluminum alloy heat-dissipating housing, the OTN-9573S connects host devices to modern 4K Smart TVs and legacy office projectors simultaneously.
Highlights
- 4K Ultra HD HDMI Output
- Full HD 1080p VGA Output
- Simultaneous Dual-Screen Output
- Mirror and Extended Desktop Modes
Key specs
- Connectivity Type
- Wired
- Max Resolution
- 4K
- Input Port
- USB-C
- Output Ports
- HDMI, VGA, Audio
Executive Overview
The Onten OTN-9573S (Model: OTN-9573 / OTN-U9573S) is a multi-port Type-C audio-video adapter and docking station engineered to expand the display and connectivity capabilities of modern laptops, MacBooks, tablets, and smartphones. Built with a dual video output controller, it converts a single USB Type-C or Thunderbolt 3/4 port into five distinct connectivity options: a 4K Ultra HD HDMI port, a 1080p Full HD VGA port, a 3.5mm AUX audio jack, a SuperSpeed USB 3.0 Type-A port (5 Gbps), and a 100W USB-C Power Delivery (PD 3.0) pass-through charging port. Enclosed in a premium anodized aluminum alloy heat-dissipating housing, the OTN-9573S connects host devices to modern 4K Smart TVs and legacy office projectors simultaneously.
Key specs
- Connectivity Type
- Wired
- Max Resolution
- 4K
- Input Port
- USB-C
- Output Ports
- HDMI, VGA, Audio
Technical Specifications
- Product Name / Model
- Onten OTN-9573S (OTN-9573 / OTN-U9573S)
- Product Type
- 5-in-1 USB-C Multi-Function Audio-Video Docking Hub
- Host Interface
- USB Type-C (Male) with DisplayPort Alt Mode / Thunderbolt 3 / 4 support
- HDMI Output
- 1x HDMI Female Port (4K Ultra HD @ 30Hz / 3840 x 2160, 1080p @ 60Hz)
- VGA Output
- 1x VGA Female Port (1080p Full HD @ 60Hz / 1920 x 1080)
- Dual Display Output
- Simultaneous HDMI + VGA output (Synchronized at 1080p @ 60Hz)
- Audio Interface
- 1x 3.5mm AUX Stereo Audio Jack (TRS 3-Pole)
- USB Data Expansion
- 1x USB 3.0 Type-A Female (5 Gbps SuperSpeed data sync)
- Power Pass-Through
- 1x USB-C Female PD 3.0 Port (Supports up to 87W–100W power input)
- Housing & Enclosure
- Anodized Aluminum Alloy + ABS Heat-Dissipating Body
- Plug and Play
- Driverless setup across Windows, macOS, ChromeOS, iPadOS, and Android
- Dimensions & Weight
- Approx. 125 x 45 x 15 mm; Weight: ~65 g
Core Features & Benefits
1. Dual Video Output (4K HDMI & 1080p VGA)
4K Ultra HD HDMI Output
Streams digital video up to 4K UHD (3840 x 2160 @ 30Hz) or 1080p @ 60Hz with multi-channel uncompressed digital audio passthrough for 4K Smart TVs, monitors, and AV receivers.
Full HD 1080p VGA Output
Delivers clear analog video up to 1080p (1920 x 1080 @ 60Hz) for legacy desktop monitors, classroom displays, and conference room projectors.
Simultaneous Dual-Screen Output
Allows users to drive an HDMI display and a VGA display at the same time. When both video outputs are utilized simultaneously, the output automatically synchronizes at 1080p @ 60Hz across both screens.
Mirror and Extended Desktop Modes
Supports duplicate (mirror) display mode for group presentations and extended desktop mode for multi-screen workstation multitasking.
2. Integrated 3.5mm AUX Audio Output & USB 3.0 Expansion
3.5mm Stereo Audio Jack
Includes a dedicated 3.5mm AUX audio jack to output analog audio directly to external desktop speakers, headphones, or soundbars. This is critical when transmitting video over VGA, as analog VGA carries no native audio signals.
5 Gbps SuperSpeed USB 3.0 Port
Features a high-speed USB 3.0 Type-A port delivering up to 5 Gbps data synchronization bandwidth (~10x faster than legacy USB 2.0) for external hard drives, flash drives, keyboards, and mice.
3. 100W USB-C Power Delivery & Thermal Shell
100W PD 3.0 Pass-Through Charging
Equipped with a female USB-C Power Delivery port supporting up to 87W–100W power input, allowing host laptops to maintain full charging speeds while running dual displays and external drives.
Anodized Aluminum Shielded Housing
Constructed with a high-durability metallic body that dissipates internal thermal buildup, protects internal circuits, and shields against electromagnetic interference (EMI).
System Compatibility & Applications
Operating System Support
Full driverless plug-and-play operation across Microsoft Windows 11 / 10 / 8.1 / 8, Apple macOS / OS X, Google ChromeOS, iPadOS, Linux, and Android.
Device Compatibility
Compatible with Apple MacBook Pro / Air, iPad Pro / Air / Mini (USB-C models), Dell XPS, HP Spectre / Envy, Lenovo ThinkPad / Yoga, ASUS ZenBook, Chromebooks, and flagship USB-C smartphones.
Samsung DeX Support
Supports Samsung DeX desktop mode on compatible Samsung Galaxy S and Note series smartphones and Galaxy Tab tablets.
