Allien and Hjeath QU32
The Allen & Heath Qu-32 (Qu-32 Chrome / Qu-32C) is a flagship 38-in / 28-out digital mixing console featuring 32 mono mic/line inputs, 3 stereo inputs, 33 motorized faders, and a 7-inch full-color touchscreen. Engineered for live sound reinforcement, house of worship installations, theaters, touring rigs, and studio recording, the Qu-32 provides a dedicated fader per mic input for rapid, intuitive control without excessive layer swapping. Powered by a 5-core ARM processor and equipped with Allen & Heath's recallable AnalogiQ™ preamps, 4 stereo RackFX engines, Qu-Drive multitrack USB recording, and a 32x32 USB audio interface, the Qu-32 combines analogue tactile workflow with advanced digital processing.
Highlights
- Transparent Audio Capture
- Total Recall
- Dedicated Fader Per Mic Input
- Intuitive Touchscreen Navigation
Key specs
- Recording Capability
- Yes
- Channel Count
- 32
- Mixer Type
- Digital
Allen & Heath Qu-32 Digital Mixer
Product Overview
The Allen & Heath Qu-32 (Qu-32 Chrome / Qu-32C) is a flagship 38-in / 28-out digital mixing console featuring 32 mono mic/line inputs, 3 stereo inputs, 33 motorized faders, and a 7-inch full-color touchscreen. Engineered for live sound reinforcement, house of worship installations, theaters, touring rigs, and studio recording, the Qu-32 provides a dedicated fader per mic input for rapid, intuitive control without excessive layer swapping. Powered by a 5-core ARM processor and equipped with Allen & Heath's recallable AnalogiQ™ preamps, 4 stereo RackFX engines, Qu-Drive multitrack USB recording, and a 32x32 USB audio interface, the Qu-32 combines analogue tactile workflow with advanced digital processing.
Key Features & Capabilities
1. 32 AnalogiQ™ Recallable Preamps
Transparent Audio Capture
Features 32 digitally controlled, low-noise AnalogiQ™ preamplifiers with zero-crossing detection and padless 1dB-step gain stages.
Total Recall
All preamp gain settings, phantom power, and channel configurations are fully saveable and recallable via scene memories.
2. Physical SuperStrip & 7" Colour Touchscreen
Dedicated Fader Per Mic Input
33 motorized faders (32 input channels + 1 master strip) provide direct, instant access to mix levels, sends on faders, and GEQ fader flipping.
Intuitive Touchscreen Navigation
High-resolution 7-inch (800x480) color touchscreen gives immediate visual feedback and tactile access to processing, FX, routing, and system settings.
Physical SuperStrip Controls
Dedicated physical rotary knobs for key processing parameters including Gain, High-Pass Filter (HPF), 4-band Parametric EQ (PEQ), Gate threshold, Compressor threshold, and Pan.
3. Comprehensive Channel & Output Processing
Input Channels (32 Mono + 3 Stereo)
Full input channel processing featuring Gain, HPF, Noise Gate, 4-band PEQ, Compressor, Delay, and Automatic Mic Mixing (AMM).
24 Mix Outputs
Comprises 4 Mono Mixes, 7 Stereo Mixes, Main LR, 4 Stereo Groups, and 2 Stereo Matrix Outputs with 4-band PEQ, 31-band Graphic EQ (GEQ), Compressor, and Delay.
4. Dual USB Audio Workflow & DAW Control
Qu-Drive Direct Multitrack USB Recording
Built-in USB Type-A port records and plays back 18 tracks of 24-bit/48kHz WAV audio directly to/from USB hard drives without requiring a computer.
32x32 USB Audio Interface
Rear-panel USB Type-B port streams 32 input and 32 output channels simultaneously to Mac and PC DAWs (Cubase, Logic Pro, Pro Tools).
DAW MIDI Control
Converts faders and buttons into HUI or Mackie Control MIDI control surface strips.
5. dSNAKE Expansion & Ecosystem Compatibility
Cat5 Digital Snake
dSNAKE port connects via Cat5e/Cat6 cable (up to 120 meters) to remote audio racks including AR2412, AB168, and AR84 stage boxes.
Personal Monitoring & Wireless Apps
Compatible with Allen & Heath ME-1/ME-500 personal mixing systems and supports remote iPad (Qu-Pad) and iPhone/Android (Qu-You) wireless mixing apps.
Key specs
- Recording Capability
- Yes
- Channel Count
- 32
- Mixer Type
- Digital
Technical Specifications
- Model
- Allen & Heath Qu-32 Digital Mixer
- Mono Inputs
- 32 x XLR / 1/4" TRS Combo (Mic/Line)
- Stereo Inputs
- 3 x Stereo 1/4" TRS (ST1, ST2, ST3) + 1/8" TRS Aux
- Mix Outputs
- 24 x XLR (Main LR, 4 Mono Mixes, 7 Stereo Mixes, 4 Stereo Groups, 2 Stereo Matrix)
- Digital Outputs
- 1 x AES Digital Out (XLR), 2-Track Out (1/4" TRS), Alt Out (1/4" TRS)
- Faders
- 33 x 100mm Motorized Faders
- Display
- 7-Inch Color Touchscreen (800 x 480 Resolution)
- Preamps
- 32 x Recallable AnalogiQ™ Class-A Preamps
- FX Engines
- 4 x Stereo FX Engines (iLive FX Library) with dedicated Returns
- USB Recording (Qu-Drive)
- 18-Track 24-bit / 48kHz WAV Direct to USB Hard Drive
- USB DAW Interface
- 32 x 32 Channel USB B Interface (Mac / PC)
- Digital Expansion
- 1 x dSNAKE EtherCon Port (Cat5 up to 120m)
- Personal Monitoring
- Compatible with ME-1 / ME-500 Systems & Qu-You App
- Groups & DCAs
- 4 DCA Groups, 4 Mute Groups
- Dimensions (W x D x H)
- 850 mm x 500 mm x 186 mm (33.5" x 19.7" x 7.3")
- Weight
- 20 kg (44 lbs)
